Description: When the tank is empty, the wires within it are open-circuited, causing the 180K resistor to pull the switch low, resulting in the switch being open and the LEDs being OFF. As water begins to fill the tank, the wire connected to switch S1 and the positive supply is bridged by the water, closing switch S1 and turning LED1 ON. As the water level continues to rise, LEDs 2, 3, and 4 illuminate progressively. Once the tank is full, the water raises the base of the BC148 transistor, driving it into saturation and activating the buzzer. To deactivate the buzzer, the SPST switch must be opened.

The described circuit operates as a water level indicator and alarm system that utilizes a combination of resistors, switches, LEDs, and a transistor to monitor the water level within a tank. At the core of the circuit is a 180K ohm resistor used to maintain the state of the switch when the tank is devoid of water. This resistor ensures that when the tank is empty, the voltage at the switch remains low, keeping the switch open and preventing any LEDs from illuminating.

As water begins to fill the tank, it creates a conductive path between the wire connected to switch S1 and the positive voltage supply. This action closes switch S1, allowing current to flow and illuminating LED1, indicating that the water level has reached a certain threshold. The progressive filling of the tank triggers a series of additional LEDs (LEDs 2, 3, and 4) to light up sequentially, providing a visual representation of the increasing water level. This cascading illumination can serve as an effective visual alert for users.

When the water level reaches its maximum capacity, it applies sufficient voltage to the base of the BC148 transistor. This causes the transistor to enter saturation, allowing a larger current to flow through the buzzer circuit, thereby activating the buzzer. The buzzer serves as an audible alarm to notify users that the tank is full, preventing overflows.

To deactivate the buzzer, an SPST (Single Pole Single Throw) switch is included in the circuit. This switch must be opened to interrupt the current flowing through the buzzer circuit, silencing the alarm. The simplicity of this design makes it suitable for various applications in water management systems, ensuring that users are promptly alerted to water levels while also providing a clear visual indication through the LEDs.When the water is empty the wires in the tank are open circuited and the 180K resistors pulls the switch low hence opening the switch and LEDs are OFF. As the water starts filling up, first the wire in the tank connected to S1 and the + supply are shorted by water.

This closes the switch S1 and turns the LED1 ON. As the water continues to fill the tank, the LEDs2, 3 and 4 light up gradually. When the water is full, the base of the transistor BC148 is pulled high by the water and this saturates the transistor, turning the buzzer ON. The SPST switch has to be opened to turn the buzzer OFF.
